Mechanical properties | |
---|---|
Mechanical life | No load plugging>10000 times |
Impact resistance | Capable of withstanding 1m height drop and 2t vehicle rolling pressure |
Environmental performance | |
Operating ambient temperature | -30℃~+50°C |
Applied Materials | |
Housing material | Thermoplastic, flame retardant grade UL94V-0 |
thrusting needle | Copper alloy, silver plated surface+thermoplastic top |
Electrical Performance | |
Rated working current | 16A or 32A |
working voltage | 220V |
insulation resistance | >1000MΩ(DC500V) |
Terminal temperature rise | <50K |
Contact impedance | 0.5mΩ Max |
Control Box Function | |
Leakage protection (restart recovery) | |
Overvoltage and undervoltage protection (self inspection recovery) | |
Overload protection (self check recovery) | |
Lightning protection |
Product selection and standard wiring | ||
---|---|---|
Model | Rated current | Cable specification |
FD-SM-EV16P | 16A | 3×2.5mm2+2×0.75mm2 |
FD-SM-EV32P | 32A | 3×6mm2+0.75mm2 |
