| Mechanical properties |
| Mechanical life |
No load plugging>10000 times |
| Impact resistance |
Capable of withstanding 1m height drop and 2t vehicle rolling pressure |
| Environmental performance |
| Operating ambient temperature |
-30℃~+50°C |
| Applied Materials |
| Housing material |
Thermoplastic, flame retardant grade UL94V-0 |
| thrusting needle |
Copper alloy, silver plated surface+thermoplastic top |
| Electrical Performance |
| Rated current and voltage |
220V AC 16A |
| insulation resistance |
＞1000MΩ(DC500V) |
| Terminal temperature rise |
＜50K |
| Withstand voltage |
2000V |
| Control Box Function |
| Leakage protection (restart recovery) |
| Overvoltage and undervoltage protection (self inspection recovery) |
| Overload protection (self check recovery) |
| Lightning protection |
